uvg266 is a video encoder for VVC/H.266 based on Kvazaar. There are 10 workloads. Overall slightly lower IPC but most metrics are similar.
Topdown overview
AMD metrics
elapsed 1226.459
on_cpu 0.789 # 12.63 / 16 cores
utime 15210.235
stime 276.940
nvcsw 20082024 # 61.17%
nivcsw 12746891 # 38.83%
inblock 0 # 0.00/sec
onblock 22496 # 18.34/sec
cpu-clock 15487261555793 # 15487.262 seconds
task-clock 15490033937969 # 15490.034 seconds
page faults 14118358 # 911.448/sec
context switches 32834801 # 2119.737/sec
cpu migrations 777121 # 50.169/sec
major page faults 2 # 0.000/sec
minor page faults 14118356 # 911.448/sec
alignment faults 0 # 0.000/sec
emulation faults 0 # 0.000/sec
branches 9488374461340 # 84.697 branches per 1000 inst
branch misses 176580290813 # 1.86% branch miss
conditional 7372985440727 # 65.814 conditional branches per 1000 inst
indirect 476354889281 # 4.252 indirect branches per 1000 inst
cpu-cycles 59222760227158 # 3.02 GHz
instructions 112113224173244 # 1.89 IPC
slots 118341567323460 #
retiring 39571594319069 # 33.4% (50.0%)
-- ucode 99400535036 # 0.1%
-- fastpath 39472193784033 # 33.4%
frontend 18606899854651 # 15.7% (23.5%)
-- latency 11404823371602 # 9.6%
-- bandwidth 7202076483049 # 6.1%
backend 18508891525338 # 15.6% (23.4%)
-- cpu 6387284955523 # 5.4%
-- memory 12121606569815 # 10.2%
speculation 2443403174228 # 2.1% ( 3.1%)
-- branch mispredict 2351990600409 # 2.0%
-- pipeline restart 91412573819 # 0.1%
smt-contention 39209393842876 # 33.1% ( 0.0%)
cpu-cycles 59233020683832 # 3.02 GHz
instructions 112104812727986 # 1.89 IPC
instructions 37336699054165 # 39.285 l2 access per 1000 inst
l2 hit from l1 1124260604785 # 5.14% l2 miss
l2 miss from l1 41199565892 #
l2 hit from l2 pf 308374602830 #
l3 hit from l2 pf 25687086559 #
l3 miss from l2 pf 8446252065 #
instructions 37327978214966 # 123.040 float per 1000 inst
float 512 106 # 0.000 AVX-512 per 1000 inst
float 256 356 # 0.000 AVX-256 per 1000 inst
float 128 4592836790618 # 123.040 AVX-128 per 1000 inst
float MMX 0 # 0.000 MMX per 1000 inst
float scalar 0 # 0.000 scalar per 1000 inst
Intel metrics
elapsed 2006.258
on_cpu 0.773 # 12.36 / 16 cores
utime 24527.891
stime 278.416
nvcsw 26498601 # 77.59%
nivcsw 7653750 # 22.41%
inblock 18235080 # 9089.10/sec
onblock 17968 # 8.96/sec
cpu-clock 24807513144133 # 24807.513 seconds
task-clock 24812450667548 # 24812.451 seconds
page faults 19015950 # 766.387/sec
context switches 34162087 # 1376.812/sec
cpu migrations 1480974 # 59.687/sec
major page faults 73 # 0.003/sec
minor page faults 19015877 # 766.384/sec
alignment faults 0 # 0.000/sec
emulation faults 0 # 0.000/sec
branches 10988043510016 # 83.506 branches per 1000 inst
branch misses 202479273078 # 1.84% branch miss
conditional 10988043555712 # 83.506 conditional branches per 1000 inst
indirect 3409696603840 # 25.913 indirect branches per 1000 inst
slots 119227881800384 #
retiring 72354003596444 # 60.7% (60.7%)
-- ucode 6177833054651 # 5.2%
-- fastpath 66176170541793 # 55.5%
frontend 28456843609843 # 23.9% (23.9%)
-- latency 12151341821410 # 10.2%
-- bandwidth 16305501788433 # 13.7%
backend 8926358411337 # 7.5% ( 7.5%)
-- cpu 5078008768688 # 4.3%
-- memory 3848349642649 # 3.2%
speculation 9809590154881 # 8.2% ( 8.2%)
-- branch mispredict 9387525599800 # 7.9%
-- pipeline restart 422064555081 # 0.4%
smt-contention 0 # 0.0% ( 0.0%)
cpu-cycles 77735101284795 # 2.39 GHz
instructions 153645864074988 # 1.98 IPC
l2 access 1975746574306 # 26.935 l2 access per 1000 inst
l2 miss 257360554948 # 13.03% l2 miss
Process overview
930 processes
570 uvg266 273549.88 4020.09
68 clinfo 16.54 6.32
38 vulkaninfo 0.76 1.50
6 php 0.16 0.23
6 glxinfo:gdrv0 0.16 0.04
4 vulkani:disk$0 0.08 0.16
2 glxinfo 0.08 0.02
2 glxinfo:cs0 0.08 0.02
2 glxinfo:disk$0 0.08 0.02
2 glxinfo:sh0 0.08 0.02
2 glxinfo:shlo0 0.08 0.02
6 clang 0.06 0.06
2 llvmpipe-0 0.04 0.08
2 llvmpipe-1 0.04 0.08
2 llvmpipe-10 0.04 0.08
2 llvmpipe-11 0.04 0.08
2 llvmpipe-12 0.04 0.08
2 llvmpipe-13 0.04 0.08
2 llvmpipe-14 0.04 0.08
2 llvmpipe-15 0.04 0.08
2 llvmpipe-2 0.04 0.08
2 llvmpipe-3 0.04 0.08
2 llvmpipe-4 0.04 0.08
2 llvmpipe-5 0.04 0.08
2 llvmpipe-6 0.04 0.08
2 llvmpipe-7 0.04 0.08
2 llvmpipe-8 0.04 0.08
2 llvmpipe-9 0.04 0.08
3 rocminfo 0.03 0.00
1 lspci 0.01 0.01
1 ps 0.00 0.01
100 sh 0.00 0.00
13 gcc 0.00 0.00
12 gsettings 0.00 0.00
8 stat 0.00 0.00
8 systemd-detect- 0.00 0.00
6 llvm-link 0.00 0.00
5 phoronix-test-s 0.00 0.00
3 gmain 0.00 0.00
2 cc 0.00 0.00
2 lscpu 0.00 0.00
2 uname 0.00 0.00
2 which 0.00 0.00
2 xset 0.00 0.00
1 date 0.00 0.00
1 dconf worker 0.00 0.00
1 dirname 0.00 0.00
1 dmesg 0.00 0.00
1 dmidecode 0.00 0.00
1 grep 0.00 0.00
1 ifconfig 0.00 0.00
1 ip 0.00 0.00
1 lsmod 0.00 0.00
1 mktemp 0.00 0.00
1 qdbus 0.00 0.00
1 readlink 0.00 0.00
1 realpath 0.00 0.00
1 sed 0.00 0.00
1 sort 0.00 0.00
1 stty 0.00 0.00
1 systemctl 0.00 0.00
1 template.sh 0.00 0.00
1 wc 0.00 0.00
1 xrandr 0.00 0.00
0 processes running
47 maximum processes
Core computation structure with one thread per thread.
238433) uvg266 cpu=2 start=5.83 finish=111.07
238434) uvg266 cpu=8 start=5.83 finish=111.05
238435) uvg266 cpu=5 start=5.83 finish=111.05
238436) uvg266 cpu=2 start=5.83 finish=111.05
238437) uvg266 cpu=9 start=5.83 finish=111.05
238438) uvg266 cpu=1 start=5.83 finish=111.05
238439) uvg266 cpu=6 start=5.83 finish=111.05
238440) uvg266 cpu=14 start=5.83 finish=111.05
238441) uvg266 cpu=13 start=5.83 finish=111.05
238442) uvg266 cpu=10 start=5.83 finish=111.05
238443) uvg266 cpu=4 start=5.83 finish=111.05
238444) uvg266 cpu=8 start=5.83 finish=111.05
238445) uvg266 cpu=15 start=5.83 finish=111.05
238446) uvg266 cpu=3 start=5.83 finish=111.05
238447) uvg266 cpu=11 start=5.83 finish=111.05
238448) uvg266 cpu=7 start=5.83 finish=111.05
238449) uvg266 cpu=0 start=5.83 finish=111.05
238450) uvg266 cpu=12 start=5.83 finish=111.05
238451) uvg266 cpu=0 start=5.86 finish=108.68
